Product Description:
Sintered Neodymium Magnet is a kind of permanent magnet made of powder metallurgy, using
neodymium, iron and boron as the main raw materials. It can provide
high pull force, and the grades range from N35 to N52. It is
available in a variety of shapes, customized according to the needs
of customers. The price is reasonable. It can be magnetized in
different directions, such as axial, multipolar, or as
customization. It is widely used in various industries and
applications, especially in the automotive, aerospace,
communications, electronics, and instrumentation industries.
Sintered Neodymium Magnet is also known as Powder Metallurgy
Magnet, because of its manufacturing process. It is an ideal choice
for those who need a high-performance magnet with reasonable cost.
Features:
- Product Name: Sintered Neodymium Magnet
- Magnetic Field Strength: High
- Magnetic Flux Density: High
- Shape: Customized
- Size: Customized
- Magnetic Orientation: Axial,Multi-polar,As Customization
- Material: Neodymium-Iron-Boron (NdFeB)
- Process: Sintered-Neo-Magnet
- Magnet Type: Neodymium-Iron-Boron
Physical Properties of Sintered Neodymium Magnet:
| Parameter Name | Parameter Values | Unit |
| Curie Temperature | 310～380 | ℃ |
| Relative Recoil Permeability | 1.02～1.05 | |
| Reversible Temperature Coefficient of Br (20~100℃) | -0.09～-0.13 | %/℃ |
| Reversible Temperature Coefficient of Hcj (20~100℃) | -0.4～-0.7 | %/℃ |
| Density | 7.50～7.70 | g/cm3 |
| Vickers Hardness | 550～700 | |
| Bending Strength | -0.09～-0.13 | MPa |
| Tensile Strength | ≥80 | MPa |
| Compressive Strength | 800 ~1050 | MPa |
| Electric Resistivity | 150 | μΩ·cm |
| Thermal Conductivity | 8～10 | W/(M·℃) |
Coefficient of Thermal Expansion
(Parallel to the orientation) | 5 | 10-6/K |
Coefficient of Thermal Expansion
(vertical to the orientation) | -1.5 | 10-6/K |
| Young's Modulus | 150～200 | GPa |
| Specific Heat(20℃～320℃) | 3.0～4.6 | J/(g·k) |
| weight loss(low weight loss products) | ≤2 | mg/cm2 |
Technical Parameters:
| Parameters | Description |
|---|
| Temperature Resistance | High |
| Magnetic Orientation | Axial,Multi-polar,As Customization |
| Size | Customized |
| Application | New Energy Cars,Wind Power Generation,Servo Motors,Traction Motors |
| Corrosion Resistance | High |
| Magnetic Field Strength | High |
| Certification | ISO9001, IATF16949, ISO14001 |
| Magnetic Performance | Stable |
| Coating | Nickel,Zinc,Epoxy |
| Price | Reasonable |
| High-Performance-Magnet | Powder-Metallurgy-Magnet, Magnetic-Alloy-Compound |
Applications:
UNMAG Sintered Neodymium Magnets are a high-performance magnetic
alloy compound made from Neodymium-Iron-Boron. With their powerful
magnetic field strength, these magnets are perfect for many
applications. With excellent magnetic orientation capabilities,
these magnets can be customized to have axial, multi-polar, or any
other orientation. They are also available with a variety of
coatings, including nickel, zinc, and epoxy. UNMAG sintered
neodymium magnets are strong, reliable, and durable and can be used
in a wide range of applications.
UNMAG sintered neodymium magnets are perfect for applications where
a strong magnetic field is needed, such as in motors, generators,
and magnetic separators. They are also ideal for applications where
high temperatures are encountered, such as in metalworking and
welding. Additionally, they can be used in medical applications
such as MRI machines, and also for audio and video applications.
These magnets are also widely used in the automotive, aerospace,
and electronics industries.
UNMAG sintered neodymium magnets are made from the highest quality
materials and are manufactured to the highest standards. With their
superior magnetic properties and excellent durability, they can be
relied upon to perform in a wide range of applications. Whether you
need a powerful magnet for a motor or generator, or for a medical
device, UNMAG sintered neodymium magnets are the perfect choice.
Customization:
Customized Sintered Neodymium Magnet by UNMAG
Brand Name: UNMAG
Place of Origin: China
Shape: Customized
Coating: Nickel,Zinc,Epoxy
Magnetic Flux Density: High
Magnetic Performance: Stable
Price: Reasonable
UNMAG is a leading supplier of high-performance magnets,
powder-metallurgy magnets and customized sintered neodymium
magnets. We provide premium quality and reliable products with
excellent magnetic flux density, stable magnetic performance and
reasonable price. Our sintered neodymium magnets are available in
various shapes and coatings (Nickel, Zinc, Epoxy).
Support and Services:
We provide technical support and services for Sintered Neodymium
Magnet. Our services include:
- 24/7 online support and troubleshooting
- Answers to frequently asked questions
- Product maintenance and repair
- Software downloads and updates
- Tutorials and user guides
Packing and Shipping:
Packaging and Shipping of Sintered Neodymium Magnet:
- The product is packed in cartons with protective wrapping to avoid
any physical damage.
- The packages are labeled with product information including size,
quantity, and destination.
- The product will be shipped via air freight or sea freight
depending on customer requirements.
